Linia Blade T / A sleek track mounted linear range available in four options with a choice of beam angles and lumen outputs. This range is ideal for applications that require wallwashing and general lighting.

Drag for 360° View
toggle zoom
  • Linia Blade T
    Linia Blade T - 3000lm & 5500lm Opal Flood
  • Linia Blade T
    Linia Blade T - 3000lm & 5500lm Opal Flood
  • Linia Blade T
    Linia Blade T - 3000lm & 5500lm Direct
  • Linia Blade T
    Linia Blade T - 3000lm & 5500lm Direct
  • Linia Blade T
    Linia Blade T - 3000lm & 5500lm Wallwash
  • Linia Blade T
    Linia Blade T - 3000lm & 5500lm Wallwash
  • Linia Blade T
    Linia Blade T - 1600lm & 2400lm Opal Flood
  • Linia Blade T
    Linia Blade T - 1600lm & 2400lm Opal Flood
  • dimensions
  • Linia Blade T
  • Linia Blade T
  • Linia Blade T
  • Linia Blade T
  • Linia Blade T
  • Linia Blade T
  • Linia Blade T
  • Linia Blade T
Features
More Info
CRI >80CRI >80
Up to 5500 lumensUp to 5500 lumens
Track mountTrack mount
Vertical MountVertical Mount
Wide BeamWide Beam
Options/StylesOptions/Styles
50,000 hours50,000 hours

The Linia Blade T linear lighting range is the ideal choice for retail lighting solutions, commercial lighting solutions and display lighting. This linear lighting solution is ideal for applications that require wall washing and general lighting.

  • Suitable for vertical mounting.
  • Cannot be joined.
  • Non dimmable.

Linia Blade T product selector

Select your options from the dropdowns in the filter row to create your product code.

Key:

compare

Add to Product Comparison

add to project

Add to my Illuma Project

add to wishlist

Add to my Illuma Favourites

IES File

IES File

LDT File

LDT File

PDF Icon

Technical Data Sheet

No.Product CodeTypeLumen Output(lm)Colour TemperatureBody ColourTrack AdaptorDownloads
 Filter
1LN30-BL/G3/830
compare add to project add to favourites
Opal Flood3000Warm WhiteBlackG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
2LN30-BL/G3/840
compare add to project add to favourites
Opal Flood3000Neutral WhiteBlackG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
3LN55-BL/G3/830
compare add to project add to favourites
Opal Flood5500Warm WhiteBlackG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
4LN55-BL/G3/840
compare add to project add to favourites
Opal Flood5500Neutral WhiteBlackG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
5LN30WL-BL/G3/830
compare add to project add to favourites
Left Wallwash3000Warm WhiteBlackG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
6LN30WL-BL/G3/840
compare add to project add to favourites
Left Wallwash3000Neutral WhiteBlackG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
7LN24-WH/G3/840
compare add to project add to favourites
Opal Flood2400Neutral WhiteWhiteG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
8LN30WR-BL/G3/830
compare add to project add to favourites
Right Wallwash3000Warm WhiteBlackG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
9LN30WR-BL/G3/840
compare add to project add to favourites
Right Wallwash3000Neutral WhiteBlackG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
10LN30D-BL/G3/830
compare add to project add to favourites
Direct3000Warm WhiteBlackG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
11LN30D-BL/G3/840
compare add to project add to favourites
Direct3000Neutral WhiteBlackG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
12LN55WL-BL/G3/830
compare add to project add to favourites
Left Wallwash5500Warm WhiteBlackG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
13LN55WL-BL/G3/840
compare add to project add to favourites
Left Wallwash5500Neutral WhiteBlackG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
14LN55WR-BL/G3/830
compare add to project add to favourites
Right Wallwash5500Warm WhiteBlackG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
15LN55WR-BL/G3/840
compare add to project add to favourites
Right Wallwash5500Neutral WhiteBlackG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
16LN55D-BL/G3/830
compare add to project add to favourites
Direct5500Warm WhiteBlackG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
17LN55D-BL/G3/840
compare add to project add to favourites
Direct5500Neutral WhiteBlackG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
18LN16-WH/G3/840
compare add to project add to favourites
Opal Flood1600Neutral WhiteWhiteG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
19LN30-WH/G3/830
compare add to project add to favourites
Opal Flood3000Warm WhiteWhiteG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
20LN30-WH/G3/840
compare add to project add to favourites
Opal Flood3000Neutral WhiteWhiteG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
21LN55-WH/G3/830
compare add to project add to favourites
Opal Flood5500Warm WhiteWhiteG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
22LN55-WH/G3/840
compare add to project add to favourites
Opal Flood5500Neutral WhiteWhiteG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
23LN30WL-WH/G3/830
compare add to project add to favourites
Left Wallwash3000Warm WhiteWhiteG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
24LN30WL-WH/G3/840
compare add to project add to favourites
Left Wallwash3000Neutral WhiteWhiteG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
25LN30WR-WH/G3/830
compare add to project add to favourites
Right Wallwash3000Warm WhiteWhiteG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
26LN30WR-WH/G3/840
compare add to project add to favourites
Right Wallwash3000Neutral WhiteWhiteG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
27LN30D-WH/G3/830
compare add to project add to favourites
Direct3000Warm WhiteWhiteG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
28LN30D-WH/G3/840
compare add to project add to favourites
Direct3000Neutral WhiteWhiteG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
29LN55WL-WH/G3/830
compare add to project add to favourites
Left Wallwash5500Warm WhiteWhiteG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
30LN55WL-WH/G3/840
compare add to project add to favourites
Left Wallwash5500Neutral WhiteWhiteG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
31LN55WR-WH/G3/830
compare add to project add to favourites
Right Wallwash5500Warm WhiteWhiteG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
32LN55WR-WH/G3/840
compare add to project add to favourites
Right Wallwash5500Neutral WhiteWhiteG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
33LN55D-WH/G3/830
compare add to project add to favourites
Direct5500Warm WhiteWhiteG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
34LN55D-WH/G3/840
compare add to project add to favourites
Direct5500Neutral WhiteWhiteG3 - 3-Circuit Switched Track AdaptorIESLDTPDF

Our latest Linia Blade T installations
