Quadroled / Ideal for the illumination of large areas that demand an efficient & powerful lighting system that can be configured up to 11500 lumens. An innovative optical lens system permits different beam angles onto surfaces for a wide & even distribution of light.



Drag for 360° View
toggle zoom
  • Quadroled
  • Quadroled
  • Quadroled
  • Quadroled
    Quadroled - Configurable Lumens
  • dimensions
  • Quadroled
  • Quadroled
  • Quadroled
  • Quadroled
Features
More Info
CRI >80CRI >80
Variable lumensVariable lumens
Up to 11500 lumensUp to 11500 lumens
Track mountTrack mount
Wide BeamWide Beam
50,000 hours50,000 hours

The Quadroled linear lighting solution is the ideal choice for retail lighting solutions, supermarket lighting and display lighting. This sleek linear lighting solution is ideal for applications that require the illumination of large areas.

  • Not suitable for vertical mounting.
  • Non dimmable.
  • Quadroled has two types of beam optics. The outer panels on either side have 4 x 25° aisle wallwash lens, ideal for vertical illumination. The central panels have 2 x 90° wide lens, ideal for general illumination.
  • Four lumen outputs can be configured by means of the DIP switches on the rear of the fitting.
  • Set the DIP switches as stated in the instruction sheet to set the desired lumen output.

Quadroled product selector

Select your options from the dropdowns in the filter row to create your product code.

Key:

compare

Add to Product Comparison

add to project

Add to my Illuma Project

add to wishlist

Add to my Illuma Favourites

IES File

IES File

LDT File

LDT File

PDF Icon

Technical Data Sheet

No.Product CodeLumen Output(lm)Beam Angle(°)Colour TemperatureBody ColourTrack AdaptorDownloads
 Filter
1TQ3115A-BL/G3/830
compare add to project add to favourites
8000 / 9120 / 10240 / 115004 x 25 + 2 x 90Warm WhiteBlackG3 - 3-Circuit Switched Track AdaptorIESLDTPDF
2TQ3115A-BL/G3/840
compare add to project add to favourites
8000 / 9120 / 10240 / 115004 x 25 + 2 x 90Neutral WhiteBlackG3 - 3-Circuit Switched Track AdaptorIESLDTPDF

Our latest Quadroled installations
